RRJOMS | Volume 5 | Issue 4 | July, 2017
July 27-29, 2017 Vancouver, Canada
10
th
International Conference on
Emerging Materials and Nanotechnology
Facile fabrication of hybrid copper-fiber conductive features with enhanced durability and ultra-low
sheet resistance for low-cost high-performance paper-based electronics
Tengyuan Zhang
Western University, Canada
T
he accelerating arrival of the Internet of Things (IoT) era creates huge demand for low-cost, high-performance paper
electronics. However, fabricating highly conductive circuit on low-cost cellulose paper is challenging due to its high
roughness and resolution loss caused by capillary effect. To address these challenges, we propose a scalable, cost-effective
method to fabricate high-performance electronics on regular cellulose paper. Taking advantage of the unique porous structure
of cellulose paper, we activate the three-dimensional electroless deposition of copper for fast generation of the hybrid copper-
fiber highly conductive structure. Currently, the sheet resistance of most PE product is 50 mΩ/sq. With the technology
mentioned above, 5 mΩ/sq (10 times better) can be easily achieved with low cost and high resolution (100 microns feature
size). Thanks to its unique copper-fiber hybrid structure, both the physical and electrical properties are greatly enhanced for
wider variety of applications. To demonstrate its promising application, a functional battery-free energy harvesting device and
a high-performance planar antenna for RFID were fabricated and tested using the proposed method.
Biography
Tengyuan Zhang is currently a PhD Candidate of Mechanical & Materials Engineering in Western University, London, Ontario. His research explores printed
flexible and stretchable electronics. Based on his research, he co-founded Nectro Inc. in 2015 with the goal of developing novel nano-materials and bringing them
to people’s life. He was awarded the Vanier Canada Graduate Scholarship in 2015 and won the Doctoral Excellence Research Award in 2016. Now, he looks
to combine cutting-edge nanotechnology and advanced chemical/material science to find a robust, low-cost solution for manufacturing high-performance, high-
resolution flexible and stretchable electronics.
tzhan55@uwo.caTengyuan Zhang, Res. Rev. J Mat. Sci. 2017
DOI: 10.4172/2321-6212-C1-002
